MISSION MAGNUM 8x6x14 sand PUMP
Kuofu Equipment Provide Mission Magnum 8x6x14 Pump and parts
8X6X14 Mission Magnum I type Horizontal Sand Pumps with tungsten carbide coating mechanical seal and ceramic coating shaft sleeve which used for well-servicing.
SPECIFICATIONS:
• Model: 8x6x14
• Capacity: 240-260 m3/h
• Head: 28-33 m
• Impeller diameter: 9-14 inch
• Recommend Power: 55/75 kW
• Materials: Hard iron, Cast iron, SS.
Mission Magnum 8x6x14 Pump Technical Data:
| Model |
Impeller
dia. |
Speed
(r/min) |
Capacity
(m3/h) |
Head
(m) |
Efficiency
(%) |
NPSH
(m) |
Power
(kw) |
| 8x6x14 | 14’’ | 1450 | 260 | 28-33 | 65 | 4.5 | 75 |
| 13’’ | 1450 | 250 | 28-33 | 65 | 4.5 | 75 | |
| 12 1/2’’ | 1450 | 240 | 28-33 | 65 | 4.5 | 55 | |
| 12’’ | 1450 | 240 | 28-33 | 65 | 4.3 | 55 | |
| 11’’ | 1450 | 220 | 28-33 | 65 | 4.0 | 55 | |
| 12’’ | 1750 | 240 | 28-33 | 65 | 4.3 | 75 | |
| 11’’ | 1750 | 220 | 28-33 | 65 | 4.0 | 75 |
